WE CUSTOM BUILD THE FINEST BALERS IN THE WORLD
Engineered for dependability and structural soundness, MSI Balers assure high performance and low maintenance. This proven money maker maximizes payload and minimizes labor, giving the high volume user an efficient means of generating recyclable income.
Features Include:
Technical Specifications
| Pump | Hydraulic Gear Type Up to 17 GPM @ 1 800 RPM |
| Cylinder | Bore - 6 " Stroke - 42 " Rod - 4 " |
| Line Pressure | 2 100 PSI = Compact Force 59 367 lbs. |
| Cycle Time | 28 Seconds |
| Finish | Blue |
| Ejector System | Heavy Duty Chain |
| Machine Size | Height - 133 " Width - 79 " Depth - 38 " |
| Bale Chamber | Height - 42 " Width - 60 " Depth - 30" |
| Chamber Floor | 3/16 " Plate with Structural Steel Channel |
| Chamber Sides | 3/16 " Plate with ½" Flat Bar and 4 " x 4 " x ¼ " An |
| Shipping Weight | 5 450 lbs. |
| Bale Weights | 800 - 1 000 lbs. |
| Amps 230 Volts | 41 Amps |
| Amps 460 Volts | 20 Amps |
Options Include:
|
- Single Phase Motor - |
|
- Cart Dumps and Rear Feed Options - |
|
- Hinged or Extra Material Retainer Dogs - |
|
- Please Contact Manufacturer for Special Requirements - |
Will your MSI Baler fit where you need it? Check our easy-to-understand space schematic:
